A replacement mechanical gasket set featuring a mint green circular gasket and a black circular metal plate with a central silver shaft and spring assembly, shown on a white background.
SKU 18-3498

Johnson/Evinrude & Suzuki Outboard Diaphragm Kit | 18-3498

by SIERRA
Availability:
in stock, ready to be shipped
$41.69 - $41.69
$41.69
$41.69 - $41.69
$41.69

The Sierra 18-3498 diaphragm kit for Suzuki and Johnson/Evinrude is a direct replacement for select OEM diaphragm kits. See OEM interchange and engine fitment information for details.

  • Fits: Suzuki DF9.9 (2005-16) / DF15 (2005-12)
  • Fits: Johnson/Evinrude 9.9/15HP (2005-07) 4-Stroke
OEM INTERCHANGE

Johnson/Evinrude Outboard:

  • 5036216
  • 5037584

Suzuki Outboard:

  • 15170-94J00
  • 15170-94J01
  • 15170-94J02
  • 15170-94J03
  • 15170-94J0V
A black padlock icon centered inside a black circle on a transparent checkerboard background.

Warranty

Sierra's limited lifetime warranty. Read more about warranty policies here.

California Proposition 65 Warning WARNING Cancer or Reproductive Harm — www.P65Warnings.ca.gov
  • Fits: Suzuki DF9.9 (2005-16) / DF15 (2005-12)
  • Fits: Johnson/Evinrude 9.9/15HP (2005-07) 4-Stroke

Logistics

  • Dimensions parcel depth, ["]: 1.75007524
  • Dimensions parcel height, ["]: 3.80007114
  • Dimensions parcel width, ["]: 4.95006884
  • Parcel weight, [lbs]: 0.0441

Engine Fitment for 18-3498

Brand Engine Model Year Serial Number Range Horsepower
Johnson/Evinrude Outboard J10RL4SOA 2005 — 9.9
Johnson/Evinrude Outboard J10EL4SOR 2005 — 9.9
Johnson/Evinrude Outboard J10TE4SOA 2005 — 9.9
Johnson/Evinrude Outboard J10TEL4SOA 2005 — 9.9
Johnson/Evinrude Outboard J10R4SOA 2005 — 9.9
Johnson/Evinrude Outboard J10TBL4SOB 2005 — 9.9
Johnson/Evinrude Outboard J15EL4SOS 2005 — 15
Johnson/Evinrude Outboard J15R4SOA 2005 — 15
Johnson/Evinrude Outboard J15TE4SOA 2005 — 15
Johnson/Evinrude Outboard J15TEL4SOA 2005 — 15
Johnson/Evinrude Outboard J15RL4SOA 2005 — 15
Johnson/Evinrude Outboard J10R4SDM 2006 — 9.9
Johnson/Evinrude Outboard J10TE4SDM 2006 — 9.9
Johnson/Evinrude Outboard J10TEL4SDM 2006 — 9.9
Johnson/Evinrude Outboard J10EL4SDA 2006 — 9.9
Johnson/Evinrude Outboard J10RL4SDM 2006 — 9.9
Johnson/Evinrude Outboard J10TBL4SDE 2006 — 9.9
Johnson/Evinrude Outboard J15EL4SDC 2006 — 15
Johnson/Evinrude Outboard J15R4SDM 2006 — 15
Johnson/Evinrude Outboard J15RL4SDM 2006 — 15
Johnson/Evinrude Outboard J15TE4SDM 2006 — 15
Johnson/Evinrude Outboard J15TEL4SDM 2006 — 15
Johnson/Evinrude Outboard J10EL4SUM 2007 — 9.9
Johnson/Evinrude Outboard J10TEL4SUB 2007 — 9.9
Johnson/Evinrude Outboard J10R4SUB 2007 — 9.9
Johnson/Evinrude Outboard J10RL4SUB 2007 — 9.9
Johnson/Evinrude Outboard J10TBL4SUD 2007 — 9.9
Johnson/Evinrude Outboard J10BL4SUM 2007 — 9.9
Johnson/Evinrude Outboard J10TE4SUB 2007 — 9.9
Johnson/Evinrude Outboard J15EL4SUR 2007 — 15
Johnson/Evinrude Outboard J15TEL4SUB 2007 — 15
Johnson/Evinrude Outboard J15R4SUB 2007 — 15
Johnson/Evinrude Outboard J15RL4SUB 2007 — 15
Johnson/Evinrude Outboard J15TE4SUB 2007 — 15
Suzuki Outboard DF9.9MLK5 2005 510001-519999 9.9
Suzuki Outboard DF9.9MSK5 2005 510001-519999 9.9
Suzuki Outboard DF9.9RLK5 2005 510001-519999 9.9
Suzuki Outboard DF9.9ELK5 2005 510001-519999 9.9
Suzuki Outboard DF15ELK5 2005 510001-519999 15
Suzuki Outboard DF15MSK5 2005 510001-519999 15
Suzuki Outboard DF15ESK5 2005 510001-519999 15
Suzuki Outboard DF9.9MSK6 2006 680001-689999 9.9
Suzuki Outboard DF9.9ELK6 2006 680001-689999 9.9
Suzuki Outboard DF9.9MLK6 2006 680001-689999 9.9
Suzuki Outboard DF9.9RLK6 2006 680001-689999 9.9
Suzuki Outboard DF15ELK6 2006 680001-689999 15
Suzuki Outboard DF15ESK6 2006 680001-689999 15
Suzuki Outboard DF15MSK6 2006 680001-689999 15
Suzuki Outboard DF9.9ELK7 2007 780001-789999 9.9
Suzuki Outboard DF9.9MLK7 2007 780001-789999 9.9
Suzuki Outboard DF9.9MSK7 2007 780001-789999 9.9
Suzuki Outboard DF9.9RLK7 2007 780001-789999 9.9
Suzuki Outboard DF15ELK7 2007 780001-789999 15
Suzuki Outboard DF15MSK7 2007 780001-789999 15
Suzuki Outboard DF15ESK7 2007 780001-789999 15
Suzuki Outboard DF9.9RLK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9THXK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9TXK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9THLK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9TLK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9ELK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9MLK8 2008 880001-889999 9.9
Suzuki Outboard DF9.9MSK8 2008 880001-889999 9.9
Suzuki Outboard DF15ELK8 2008 880001-889999 15
Suzuki Outboard DF15ESK8 2008 880001-889999 15
Suzuki Outboard DF15MSK8 2008 880001-889999 15
Suzuki Outboard DF9.9THLK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9TLK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9ELK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9MLK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9MSK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9RLK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9THXK9 2009 980001-989999 9.9
Suzuki Outboard DF9.9TXK9 2009 980001-989999 9.9
Suzuki Outboard DF15MSK9 2009 980001-989999 15
Suzuki Outboard DF15ELK9 2009 980001-989999 15
Suzuki Outboard DF15ESK9 2009 980001-989999 15
Suzuki Outboard DF8ALK10 2010 010001-019999 8
Suzuki Outboard DF8ARLK10 2010 010001-019999 8
Suzuki Outboard DF9.9TXK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9ALK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9AS10 2010 010001-019999 9.9
Suzuki Outboard DF9.9AELK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9AESK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9ARLK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9THLK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9THXK10 2010 010001-019999 9.9
Suzuki Outboard DF9.9TLK10 2010 010001-019999 9.9
Suzuki Outboard DF15ELK10 2010 010001-019999 15
Suzuki Outboard DF15SK10 2010 010001-019999 15
Suzuki Outboard DF15ESK10 2010 010001-019999 15
Suzuki Outboard DF8AL 2011 110001-119999 8
Suzuki Outboard DF8ARL 2011 110001-119999 8
Suzuki Outboard DF9.9THX 2011 110001-119999 9.9
Suzuki Outboard DF9.9THL 2011 110001-119999 9.9
Suzuki Outboard DF9.9AEL 2011 110001-119999 9.9
Suzuki Outboard DF9.9AES 2011 110001-119999 9.9
Suzuki Outboard DF9.9AL 2011 110001-119999 9.9
Suzuki Outboard DF9.9ARL 2011 110001-119999 9.9
Suzuki Outboard DF9.9AS 2011 110001-119999 9.9
Suzuki Outboard DF15EL 2011 110001-119999 15
Suzuki Outboard DF15ES 2011 110001-119999 15
Suzuki Outboard DF15S 2011 110001-119999 15
Suzuki Outboard DF9.9THX 2012 210001-219999 9.9
Suzuki Outboard DF9.9AES 2012 210001-219999 9.9
Suzuki Outboard DF9.9ARL 2012 210001-219999 9.9
Suzuki Outboard DF9.9AS 2012 210001-219999 9.9
Suzuki Outboard DF9.9THL 2012 210001-219999 9.9
Suzuki Outboard DF9.9AEL 2012 210001-219999 9.9
Suzuki Outboard DF9.9AL 2012 210001-219999 9.9
Suzuki Outboard DF15EL 2012 210001-219999 15
Suzuki Outboard DF15ES 2012 210001-219999 15
Suzuki Outboard DF15S 2012 210001-219999 15
Suzuki Outboard DF9.9ARL 2013 310001-319999 9.9
Suzuki Outboard DF9.9THL 2013 310001-319999 9.9
Suzuki Outboard DF9.9THX 2013 310001-319999 9.9
Suzuki Outboard DF9.9AEL 2013 310001-319999 9.9
Suzuki Outboard DF9.9AES 2013 310001-319999 9.9
Suzuki Outboard DF9.9AL 2013 310001-319999 9.9
Suzuki Outboard DF9.9AS 2013 310001-319999 9.9
Suzuki Outboard DF9.9AEL 2014 410001-419999 9.9
Suzuki Outboard DF9.9AL 2014 410001-419999 9.9
Suzuki Outboard DF9.9AES 2014 410001-419999 9.9
Suzuki Outboard DF9.9AS 2014 410001-419999 9.9
Suzuki Outboard DF9.9AL 2015 510001-519999 9.9
Suzuki Outboard DF9.9AS 2015 510001-519999 9.9
Suzuki Outboard DF9.9ARL 2015 510001-519999 9.9
Suzuki Outboard DF9.9AEL 2015 510001-519999 9.9
Suzuki Outboard DF9.9AES 2015 510001-519999 9.9
Suzuki Outboard DF9.9AES 2016 610001-619999 9.9
Suzuki Outboard DF9.9AL 2016 610001-619999 9.9
Suzuki Outboard DF9.9AS 2016 610001-619999 9.9
Suzuki Outboard DF9.9AEL 2016 610001-619999 9.9

Free Shipping

When you spend $50+

Contact Support

Talk to a real human on our team

Find a Dealer

Find your local SIERRA or Dometic dealer

Interchange for Johnson/Evinrude & Suzuki Outboard Diaphragm Kit | 18-3498

Johnson/Evinrude Outboard:

  • 5036216
  • 5037584

Suzuki Outboard:

  • 15170-94J00
  • 15170-94J01
  • 15170-94J02
  • 15170-94J03
  • 15170-94J0V
